Cervelo Caledonia Rival AXS - 2025
Details
A BIKE FOR THE WAY RIDERS RIDE
Caledonia doesn’t fit in a box nicely, and we like it that way. It was conceived on our Thursday night rides—routes that often play fast and loose with ‘road ride.’ Modern road riders are looking for bikes to handle long-distance, high pace, no limits, and offer maximum fun—the Caledonia delivers performance, comfort, and speed. Oh, and you can fit a 34mm tire in there. Or 31mm with fenders.
REMOVABLE FDM
Our bolt-on front derailleur mount is made from high-strength aluminum alloy and attaches to the frame with two countersunk screws. This allows for easy replacement in the event of damage but also enables you to adapt to new standards as they become available or remove the front derailleur mount completely if you choose a 1x system.
INTEGRATED ACCESSORY MOUNTS
Integrated mounts enable the use of fenders, lights, and computers without compromising the aerodynamics or structure of your bike. The built-in mount systems provide a simple and clean-looking solution.
| Frame Size | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Reach | mm | 360 | 369 | 378 | 387 | 396 | 405 |
| Stack | mm | 505 | 530 | 555 | 580 | 605 | 630 |
| Head Tube Angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
| Front Center | mm | 579.4 | 581.7 | 591.5 | 608.5 | 626 | 643 |
| Bottom Bracket Drop | mm | 76.5 | 76.5 | 74 | 74 | 71.5 | 71.5 |
| Head Tube Length | mm | 89.5 | 109.9 | 136 | 162.3 | 191.2 | 217.5 |
| Top Tube Length | mm | 502 | 522 | 543 | 565 | 581 | 598 |
| Seat Tube Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| Standover Height | mm | 701 | 741 | 773 | 796 | 823 | 847 |
| Trail | mm | 60 | 60 | 60 | 60 | 60 | 60 |
| Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Fork Offset | mm | 59 | 53 | 50 | 50 | 50 | 50 |
| Wheelbase | mm | 982.2 | 984.5 | 995.2 | 1012.3 | 1030.7 | 1047.8 |
| Chainstay Length | mm | 415 | 415 | 415 | 415 | 415 | 415 |
| Frame Size | Rider Height (cm) | Rider Height (in) |
|---|---|---|
| 48 | 150 - 160 | 4'11" - 5'3" |
| 51 | 160 - 168 | 5'3" - 5'6" |
| 54 | 168 - 176 | 5'6" - 5'9" |
| 56 | 176 - 184 | 5'9" - 6'0 |
| 58 | 184 - 192 | 6'0" - 6'3" |
| 61 | 192 - 200 | 6'3" - 6'7" |
Specs
| Fork | Cervélo All-Carbon, Tapered Caledonia Fork |
|---|---|
| Wheels | Vision Team i23 Disc, 23mm IW, direct pull, 12x100mm, centerlock, tubeless compatible |
| Tires | Vittoria Corsa N.EXT TLR G2.0 700x32c |
| Bottom Bracket | SRAM DUB, BBright |
| Crankset | SRAM Rival AXS E1, 48/35T, DUB |
| Shifters | SRAM Rival AXS E1 |
| Front Derailleur | SRAM Rival AXS E1 |
| Rear Derailleur | SRAM Rival AXS E1 |
| Cassette/Freewheel | SRAM Rival D1, 10-36T, 12-Speed |
| Chain | SRAM Rival E1 |
| Rotors | SRAM Paceline Centerlock |
| Brake Levers | SRAM Rival AXS E1 |
| Handlebars | Cervélo AB07 Alloy, 31.8mm clamp |
| Headset | FSA IS2 1-1/8, 36° x 45° / 1-1/2, 36° x 45° |
| Seatpost | Cervélo SP19 Carbon 27.2 |
| Pedals | Sold Separately |
| Saddle | Cervélo Saddle |
| Extras |
Cervélo Removeable Fender Mounts Cervélo Front Computer/Accessory Mount 810 Cervélo Rear Accessory Mount |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Emerald/Cream / 48cm / 700c | 0616663229520 | 0L0CAAVX1A48 | |
| Emerald/Cream / 51cm / 700c | 0616663229537 | 0L0CAAVX1A51 | |
| Emerald/Cream / 54cm / 700c | 0616663229544 | 0L0CAAVX1A54 | |
| Emerald/Cream / 56cm / 700c | 0616663229551 | 0L0CAAVX1A56 | |
| Emerald/Cream / 58cm / 700c | 0616663229568 | 0L0CAAVX1A58 | |
| Emerald/Cream / 61cm / 700c | 0616663229575 | 0L0CAAVX1A61 | |
| Vanilla/Cherry / 48cm / 700c | 0616663229582 | 0L0CAAVX2A48 | |
| Vanilla/Cherry / 51cm / 700c | 0616663229599 | 0L0CAAVX2A51 | |
| Vanilla/Cherry / 54cm / 700c | 0616663229605 | 0L0CAAVX2A54 | |
| Vanilla/Cherry / 56cm / 700c | 0616663229612 | 0L0CAAVX2A56 | 210000091918 |
| Vanilla/Cherry / 58cm / 700c | 0616663229629 | 0L0CAAVX2A58 | |
| Vanilla/Cherry / 61cm / 700c | 0616663229636 | 0L0CAAVX2A61 |
